modular Pitless Multi Deck Road Weighbridge for container transportation

Name: modular Pitless Multi Deck Road Weighbridge for container transportation
Brand: SMARTWEIGH
Price: 1 USD

Brand Name : SMARTWEIGH

Model Number : HWTS 7575

Certification : ISO/CE/SGS

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiable

Payment Terms : LC, T/T, Weston Union, MoneyGram

Supply Ability : 100 sets per month

Delivery Time : 3-8 weeks

Packaging Details : Scales body with plastic film package, electronic parts with carton box

Max Capacity : 200T

Verification scale value : 10Kg

Weighing platform width : 3m/3.4m/4m/4.5m( can customized)

Weighing Platform length : 6M-30M( can customized)

Civil work type : Pitless type foundation

Weighing Mode : Digital

Name : Multi Deck Weighbridge

Use : Weighing for Trucks

Contact Now

Multi Deck Road Weighbridge Weighing Caravan On Weighbridge Truck Weight Machine

Model 7575 Road Weighbridge is a extremely durable scale for weighing vehicles' max axle load exceed 30 ton or 40 ton. Our new generation heavy duty weighbridge adopt the proven designed bridge I-type welded ribs help direct the pressure of a heavy concentrated load away from areas, securing the truck scales no deformation and stronger enough in the long terms. ZEMIC compression load cells transmit a powerful signal for accurate, reliable weighing.

Specification of Multi Deck Weighbridge:

Model	SCS-30	SCS-40	SCS-50	SCS-60	SCS-80	SCS-100	SCS-120	SCS-150
Capacity	30T	40T	50T	60T	80T	100T	120T	150T
Graduation Value	10kg	10kg	20kg	20kg	20kg	20kg	20kg	20kg
3.0×7M	*	*
3.0×9M		*	*
3.0×10M			*	*
3.0×12M			*	*
3.0×14M			*	*	*
3.0×15M			*	*	*	*
3.0×16M				*	*	*	*
3.0×18M				*	*	*	*	*
3.0×20M					*	*	*	*
3.2×12M			*	*
3.2×14M			*	*	*
3.2×16M			*	*	*	*	*
3.2×18M				*	*	*	*	*
3.2×20M				*	*	*	*	*
3.4×14M			*	*	*
3.4×16M			*	*	*	*	*	*
3.4×18M				*	*	*	*	*
3.4×21M				*	*	*	*	*

Features and Advantages of the Road Weighbridge Avery Tronix Weighbridge :

The modular design of these products allow for customization to suit your exact needs.
Every new weighbridge design undergoes rigorous lifecycle testing.
The proven design of the bridge-type U-type welded ribs help direct the pressure of a heavy load away from areas.
Divide into several panels, easy to move platforms, and container transportation.
Easy installation, calibration, and maintenance.
Automatic professional welding along the seam of each rib to the deck ensures lasting strength.
High-performance load cells, good accuracy, and reliability make clients maximum income.
Full steel stronger structure designed for concentrated loads and frequent use.
Many storage functions: Vehicle number, Tare storage, Accumulation storage and many data report output.

Our High Accuracy compression type loadcells :

Nickel plated alloy steel IP68 dual shear beam load cell
High accuracy OIML R60 C3
Capacity:10-50t
Current calibrated

modular Pitless Multi Deck Road Weighbridge for container transportation

Digital Indicator DS10 with LCD backlight:

AC/DC power supply.
User-defined printing content and format:
User-defined printing format, and be able to connect with serial printing interface and thermal printer
Reliable shield and anti-jamming:
Adopts hardware for shielding and reduces external-jamming and damage of interface.

HS code : 84238990
Delivery Port: SHANGHAI , NINGBO, QINGDAO
Trade terms: EXW, FOB, CNF,CIF, DAP, DDU,DDP
Payment terms: T/T or L/C, 30% advanced payment for production, balanced. PAYPAL, WESTION UNION.
Professional Installation: We can send technician or require local agent installation
After sales service: We can help the maintenance whenever you need

Truck Weighbridge Manufacturing Process

1. Bending Machine to Shape the Under Beams	2. CNC Cutting machine to satisfy the customized requests	3. Arching Machine

4. Automatic Welding Machine	5.Ball Blasting Machine	6. Make the surface more neatly

7. Baking paint Room	8. Installation and pre-calibration before shipping	9. Shipping Container by Sea or Railway

Truck Scale Customizations

SMARTWEIGH has a team of engineers dedicated to custom vehicle weighing applications.

Common customizations and specialty projects have included:

· Additional length/width

· Grain dump grating (full-length or partial)

· Special finishes (galvanization, coating, or color requests)

· Added deck plate thickness

· Wear plates (fully welded)

· Stainless steel

· Special side-rails

· Special filling applications

· Axle scales

· Vehicle scale refurbishing

Truck Weight Scale Civil Work Foundation Types:

1. Pitless Foundation:		Least Expensive Piers support each load bearing point Wash-out slabs sometimes included
2. Shallow Foundation:		Additional beams of concrete run the length and width of the scale Stronger than pier style foundation
3. Pit Style Foundation:		Depth of pit varies per project and is often a custom solution Must allow minimum depth for technician to access components beneath the weighbridge Can require additional care for cleaning as pit can collect debris
